Introduction：
Rubber foam insulation sheets are totally formaldehyde-free,CFC-free and can be directly exposed to the air, not harm for human health. In order to form high closed cellular rate and low thermal conductivity foam insualtion sheets, we choose NBR which is no harm to the environment as our main material and other good quality materials and use vacuum extrusion ,accurate temperature control foaming process .
Application：
It is widely used in the insulation of large tank equipment for construction, commercial and industrial purposes. It can also be used for wallboard sound insulation, sound absorption in air ducts and sound absorbing decoration in entertainment venues.
Characteristics：
Item | 0 class | B1 class | B2 class |
Structure | Closed cell | Closed cell | Closed cell |
Temperature range | -50℃~105℃ | -50℃~105℃ | -50℃~105℃ |
Average temperature Conductivity factor(w/mk) | 0.034(0℃) | 0.034(0℃) | 0.034(0℃) |
Water absorption ratio in vacuum | ≤10 | ≤10 | ≤10 |
Flammability | Difficult to burn 0 class | Flame retardant class | Flammability B2 |
Oxygen index | ≥40 | ≥32 | ≥28 |
Vertically burning | ≤30s≤250mm | ≤30s≤250mm | ≤30s≤250mm |
SDR | ≤70 | ≤75 | ≤75 |
Density | 40-80kg/m3 | 40-80kg/m3 | 40-80kg/m3 |
Crack resistance | ≥2.5N/cm | ≥2.5N/cm | ≥2.5N/cm |
Compression resilience ratio | ≥70% | ≥70% | ≥70% |
Dimension stability | ≤10.0% | ≤10.0% | ≤10.0% |
Aging resistance | Slightly crumpling, no cracks, no pin holes, not deforming | Slightly crumpling, no cracks, no pin holes, not deforming | Slightly crumpling, no cracks, no pin holes, not deforming |
